CONSTRUCTION:
Aiflon CAF3050 is made from selected asbestos fibre, natural rubber, filling material and dye. A price worthy quality of dependable performance, plus adaptability to many sealing requirements makes this jointing the most economical sheet packing choice in the wide range of industrial fields.
Aiflon 3050G is CAF 3050 with both graphite coating
Aiflon 3050IG is CAF 3050 reinforced by wire mesh with both graphite coating
PROPERTIES & APPLICATION:
|
Item
|
Style
|
|
3050
|
3050G
|
3050IG
|
|
Tensile strength¡YMpa
|
19
|
19
|
25
|
|
Aging
coefficient
|
0.9
|
0.9
|
0.9
|
|
Loss on ignition
¡ü%
|
28
|
28
|
28
|
|
Compressibility
¡Y%
|
12¡à5
|
12¡à5
|
12¡à5
|
|
Recovery
¡Y%
|
45
|
45
|
45
|
|
Density g/cm3
|
1.8~2.0
|
1.8~2.0
|
2.0~2.2
|
|
Tmax: ¡æ
|
500
|
550
|
550
|
|
Pmax: Mpa
|
12.0
|
12.0
|
20
|
|
Normal color
|
Purple red
|
Graphite
|
Graphite
|
|
Resistance
to media
|
Water, seawater, steam, diluted acid & alkali, gases, alcohols, salt solutions etc. under temperature and pressure.
|
Available colour: Purple, Black, grey, etc.
Also available with anti-stick￡o3050S￡¬3050GS￡¬3050IGS
FORMS OF SUPPLY:
Sheets￡oThickness: 0.4~6mm
12000¡á1500mm; 2000¡á4000mm;
1500¡á1500mm; 1500¡á1000mm;
1270¡á1270mm; 3810¡á1270mm
Cut gaskets￡o
CAF G3050, G3045G, G3045IG
Dimensions according to drawings or specifications and standards
